Suitable for small and medium-sized conference rooms, banquet halls, command centers, and multi-functional halls.
* The box is made of nylon fiber reinforced material, mold pressed, light weight and high sound pressure design .
* The hard and thick rigid mesh is stamped in one piece and covered with high-sound-transmittance mesh cotton, which effectively prevents dust or liquid from invading and affecting the sound quality, protects the speaker, and significantly increases the service life of the speaker .
* Equipped with 4 5-inch ferrite mid-bass speakers and 2 44mm neodymium compression tweeters, the treble is bright and rich, the low frequency is rich, and the vocals are clear and distinct .
* The crossover adopts a single drive mode, and the tweeter uses ultra-short waveguide technology to achieve excellent and good directivity, uniform sound field coverage, high sound pressure level output, and fast transient response, achieving performance-level high sound pressure and clarity.
* The product is ultra-light and thin, with aluminum alloy pendants, and can be assembled by one person .
Rated power |
400W |
Peak power |
1600W |
Nominal impedance |
16Ω |
Frequency range (-10dB) |
100Hz~17KHz |
Sensitivity (±3dB) |
98dB(1M/1W) |
Maximum sound pressure level (rated/peak) |
112dB/118dB |
Bass |
5" woofer x 4 |
Treble |
44mm" neodymium compression tweeter × 2 |
Coverage angle |
(H) 100°(V) 0-10° adjustable |
Dimensions (HxWxD) |
296 × 448 × 156 mm |
Weight |
13.8Kg |
