Suitable for various medium and large lecture halls , multi-function halls, banquet halls, auditoriums and other indoor sound reinforcement places.
* This product is an 18-inch linear array low-frequency speaker, which is combined with a full-range speaker to form a linear array speaker system .
* Using an 18" (100mm voice coil) low-frequency driver, the low-frequency limit can be extended to 40Hz .
* The newly designed driver cooling system can quickly dissipate the heat energy generated by the voice coil , ensuring the stability of the driver under long-term large dynamic conditions .
* The box structure is made of high-density birch wood, and the surface of the box is treated with high-strength paint to prevent collision and increase service life .
* The hanging device adopts a new mold design, which is convenient and quick to install and can efficiently complete on-site installation and stacking .
Rated power |
800W |
Peak Power |
3200W |
Nominal impedance |
8Ω |
Frequency range (-10dB) |
40Hz-400Hz |
Sensitivity (±3dB) |
101dB (1M/1W) |
Maximum sound pressure level (rated/peak) |
130dB/136dB |
Speaker unit |
18" (100mm voice coil) × 1 |
Size (H×W×D) |
610×923× 560 mm |
Net weight |
57 kg |
