KF-D212 Linear Array Speaker

The Details Related Solution Related Cases Related Video Download




Description:


It is used in performances, stadiums, theaters, banquet halls, multipurpose halls and various high-end occasions.


Feature:


* Adopt two 12-inch ferrite woofers and one 3-inch tweeter.

* Adopt a round chamfer structure, the surface is spray-painted, high-grade and wear-resistant.

* The mesh cover adopts the powder spraying process to increase the strength, improve the service lifespan and oxidation resistance.

* The frequency divider has been adjusted by professional equipment to provide high vocal reproduction, strong penetration, and low distortion.

* With hanging parts, it supports suspended and stacked installation; three-point hanging, compact connection, easy installation and disassembly.

* Professional speaker sockets and plugs with good electrical characteristics.


Specification:


Model

KF-D212

Rated power

Woofer800W, Tweeter160W

Peak power

Woofer3200W, Tweeter640W

Nominal impedance

Woofer: 8 Ω, Tweeter: 8 Ω

Frequency range

50Hz-20KHz

Sensitivity

LF: 104dB, HF: 109dB (1M/1W)

Maximum SPL (rated/peak)

Woofer: 13dB/13dB, Tweeter: 131dB/137dB

Woofer

12Woofer × 2

Tweeter

3" Tweeter × 1

Horizontal coverage angle (-6dB)

100°

Vertical coverage angle (-6dB)

10°

Net weight

44 kg

Dimension (H×W×D)

363×924×515mm
