1．High breaking air switch with dual protection of overload and short circuit.
2．With A.B.C three-phase working indicators.
3．Adopt 2-pin and 3-pin universal sockets, convenient to use; imported terminal input, and single 32A bakelite plug output.
|
Power supply |
TN-S system AC 380V±10%, frequency 50Hz±5% |
|
No-load power |
10W |
|
Power factor |
PF≥0.98 |
|
Rated power |
12 channels×4kW, suitable for any load |
|
Shell material |
Cold-rolled plate |
|
Power interface |
12 power output interfaces, 1 socket interface |
|
Working environment temperature |
-10℃～45℃ |
|
Protection class |
IP20 |
|
Dimensions |
International standard 3U |
|
Product dimensions (L×W×H) |
485×415×133mm |
|
Packaging dimensions (L×W×H) |
535×465×205mm (carton) |
|
Packaging gross weight |
11.8kg |
|
Product net weight |
11.2kg |
