1. Dimming: 0-100% electronic linear dimming with jitter-free smooth dimming technology.
2. Strobe: 0-25 times per second electronic strobe with adjustable speed, built-in random strobe or pulse strobe.
3. Color mixing system: Warm white and cool white, 2 colors with linear color mixing for color temperature adjustment.
4. Tilt angle: 0°-60° motorized linear adjustable.
5. Features: High luminous efficiency, uniform light mixing, good heat dissipation with fin-type heatsink, stable performance.
6. Display interface: Digital tube display with 4 mechanical buttons.
7. Temperature protection: Built-in NTC temperature detection function, intelligently reduces the LED output power when the LED operates over temperature.
|
Input voltage |
AC 110-240V, 50/60Hz |
|
Rated power |
50W |
|
Power factor |
PF≥0.90 |
|
Light source |
48*0.5W LED (WW24+CW24) |
|
Average LED lifespan |
50000H |
|
Color temperature |
3200K-6500K |
|
Color tolerance |
SDCM≤3 |
|
Luminous flux |
3365 lm |
|
CRI |
Ra≥95 |
|
Beam angle |
105° |
|
Control mode |
DMX512 protocol, with built-in Master-slave mode, Manual control mode |
|
Channel mode |
Compact mode 3CH, Standard mode 6CH |
|
Casing material |
Die-cast aluminum + iron |
|
Power connector |
1 power input connector |
|
Signal connector |
1 DMX512 input connector, 1 DMX512 output connector |
|
Operating temperature |
-10℃～45℃ |
|
IP rating |
IP30 |
|
Opening size |
560×145mm |
|
Product dimensions (L×W×H) |
580×160×91mm |
|
Package dimensions (L×W×H) |
635×230×165mm (carton) |
|
Package gross weight |
5.3kg |
|
Product net weight |
4.9kg |
