1. Optical system: Adopts high-temperature resistant and high-transmittance optical glass lens set (3-layer coating), with a φ44mm aperture output lens.
2. Dimming: 0-100% electronic linear dimming with jitter-free smooth dimming technology.
3. Strobe: 0-25 times per second electronic strobe with adjustable speed, built-in random strobe or pulse strobe.
4. Features: Equipped with one input and one output daisy-chain power cable and signal cable (each 1.5 meters long), improving on-site lighting installation efficiency.
5. Pattern framing system: 4 independent manual framing shutters, adjustable at any angle to shape the light beam.
6. Display interface: LCD display with 4 mechanical buttons.
|
Input voltage |
AC 110-240V, 50/60Hz |
|
Rated power |
100W |
|
Power factor |
PF≥0.98 |
|
Light source |
100W white light LED COB |
|
Color temperature |
3200K |
|
Color tolerance |
SDCM≤3 |
|
Luminous flux |
1100 lm |
|
CRI |
Ra≥80 |
|
Beam angle |
19° |
|
Control mode |
DMX512 protocol, with built-in Master-slave mode, Manual control mode |
|
Channel mode |
Standard mode 2CH |
|
Casing material |
Die-cast aluminum |
|
Power connector |
1 power input connector |
|
Signal connector |
1 DMX512 input connector, 1 DMX512 output connector |
|
Operating temperature |
-10℃～45℃ |
|
IP rating |
IP20 |
|
Product dimensions (L×W×H) |
390×190×135mm |
|
Package dimensions (L×W×H) |
480×240×190mm (carton) |
|
Package gross weight |
3.1kg |
|
Product net weight |
2.6kg |
