1. Optical system: Adopts high-temperature resistant and high-transmittance optical glass lens set (5-layer coating) + φ174mm Fresnel lens.
2. Dimming: 0-100% electronic linear dimming with jitter-free smooth dimming technology.
3. Strobe: 0-25 times per second electronic strobe with adjustable speed, built-in random strobe or pulse strobe.
4. Focusing: Linear motorized focusing.
5. Color mixing system: Warm white and cool white, 2 colors with linear color mixing for color temperature adjustment.
6. Software update: Supports DMX signal update and cloud server remote online update for fast and convenient software updates.
7. Display interface: Features a 1.8-inch blue screen LCD display; supports easy switching between Chinese and English languages, equipped with 4 mechanical buttons.
8. Temperature protection: Built-in NTC temperature detection function, intelligently reduces the LED output power when the LED operates over temperature.
|
Input voltage |
AC 110-240V, 50/60Hz |
|
Rated power |
200W |
|
Power factor |
PF≥0.98 |
|
Light source |
200W white light LED COB |
|
Average LED lifespan |
50000H |
|
Color temperature |
2700K-7000K |
|
Color tolerance |
SDCM≤3 |
|
Luminous flux |
10845 lm |
|
CRI |
Ra≥95 R9≥85 R15≥90 |
|
Optical angle |
12°-36° |
|
Control mode |
DMX512 protocol, RDM protocol, with built-in Master-slave mode, Auto run mode, Manual control mode |
|
Channel mode |
Compact mode 3CH, Standard mode 6CH |
|
Casing material |
Die-cast aluminum |
|
Power connector |
1 power input connector, 1 power output connector |
|
Signal connector |
1 DMX512 input connector, 1 DMX512 output connector |
|
Operating temperature |
-10℃～45℃ |
|
IP rating |
IP20 |
|
Product dimensions |
(L×W×H) 412.5×273×236mm |
|
Package dimensions |
(L×W×H) 485×350×310mm (carton) |
|
Package gross weight |
7.8kg |
|
Product net weight |
6.5kg |
