TS-F156MTS Motorized Paperless Interactive Monitor Lift

The Details Related Solution Related Cases Related Video Download


Description:


This product uses intelligent control technology, takes intelligent terminal as the application concept, and adopts original rail design. With one-key operation, it can automatically complete the startup, LCD screen rise, elevation and other actions. The desktop is beautiful and atmospheric, and it is space-saving. It is very convenient to use and has anti-theft, dust-proof, and desktop beautification functions. It can be widely used in conferences, office hotels, teaching studios and other occasions to meet the needs of customers for diversified system expansion and office environment automation. It is your ideal assistant in office and teaching.


Features:


* It adopts a single-screen paperless smart desktop design and is equipped with a paperless conference terminal. It can display the graphics required for the meeting and the names of the meeting guests, perfectly realizing the powerful interactive paperless conference functions.

* The touch ultra-thin high-definition display screen and the lifter are integrated into a design with no exposed connecting wires, no connecting back panel, and no exposed screws, ensuring that the lifting display touch screen is beautiful as a whole.

* With integrated microphone lift, the microphone lift has an automatic straightening function. When the microphone stem is bent, the machine can automatically straighten the stem when it is turned off without damaging the stem.

* The equipment adopts an all-aluminum structure, high-quality aluminum materials plus CNC precision carving processing, the display frame and chassis are all made of aluminum alloy, making the overall equipment exquisite, lightweight, beautiful and atmospheric.

* The surface treatment of the equipment is anodizing, with bright color . It can be processed by sandblasting, brushing and other processes, and various colors can be customized .

* The device panel is only 3mm thick and 70mm wide, taking up little space.

* The transmission structure is specially processed to minimize noise. The product transmission method uses high-quality tensile belts, high-precision slider guides and linear bearings, and stepper motors as driving power; the central control protocol has strong compatibility and is compatible with all control hosts. After the control device rises, the screen automatically powers on, and after it falls, the screen automatically powers off, which is energy-saving and environmentally friendly.

* It uses a 15.6-inch ultra-thin LCD touch screen display with a resolution of 1920*1080P. The display effect is clear and bright, and the backlight design can be adjusted to prevent fatigue caused by excessive brightness or darkness.

* It supports two signal inputs, HDMI and VGA. When only one signal is input, the screen will automatically identify the signal. When two signals are input at the same time, they can be manually switched through the panel buttons. When there is no signal input, the screen automatically enters power saving mode.

* The equipment can be centrally controlled through the central control software and can be controlled by the host computer. All indoor equipment can be raised or lowered with one button.

* The built-in loop-through output power socket can supply power to the terminal, reducing the wiring of the terminal power socket, making the wiring on the project site neater and more beautiful.

* The desktop panel has a USB interface, which can be used to browse or upload files by connecting a USB flash drive.

* The lifting speed is adjustable, the default is 13 seconds. ( 9S, 13S, 16S can be adjusted through the serial port )


Specifications:


Touchscreen

Touch Support

Lifting time

Default 13S (three levels of adjustment: 9S, 13S, 16S )

Elevation angle

0-25°, fully ergonomic, without blocking sight and face

Product size

555×70×650mm

Panel size

555×70×3mm

Chassis size

538.2×59×647mm

Desktop opening size

540.2×62mm (physical opening recommended)

Panel sink size

556×71×8mm (length*width*thickness) (physical opening recommended)

Environmental conditions

-20℃50℃, relative humidity ≤70%

Screen size

15.6"

Screen ratio

16:9

Screen resolution

1920×1080

Video interface

1-channel VGA, 1-channel HDMI

Control interface

1 set of 232/485 input and output interfaces; control the lifting of the display screen, support hand-in-hand connection; 1 USB interface for power on/off, 1-channel USB interface for data transmission

Microphone interface

1 set of six-core aviation line interface, which can realize the "hand in hand" series connection of multiple units

Mic rod length

409mm

Backlight type

WLED, 15K hours, with LED driver

Contrast

600:1

Brightness

250cd/

Viewing angle

45/45/20/40 (Typ.)

Power supply

AC 220V 50-60/HZ

Power consumption

25W

Machine weight

15kg

Microphone specifications:

Microphone type

Cardioid electret

Frequency response

80Hz-16KHz

Microphone input impedance

680Ω

Sensitivity

-41±1.5dB (0dB=1V/Pa,at 1KHz)

Maximum SPL

120dB

Signal-to-noise ratio

>80dB

THD

<0.1%

Power consumption

2W
