TS-F1107TS Electronic Nameplate

The Details Related Solution Related Cases Related Video Download


Description:

The product adopts a dual 7-inch LCD display design and a built-in high-performance processor, which can simultaneously display participant information such as name, title, company, meeting theme, etc.; the equipment lifting and nameplate distribution functions can be uniformly controlled through software; and the lifting and lowering of the nameplate can also be controlled by touch through the top metal touch panel .


Features:


* The product adopts a dual-screen design, with both the front and rear screens being 7-inch IPS LCD displays with a resolution of up to 1024×600, which can display information such as conference patterns, conference guests, names of participants, titles, companies, conference themes, etc.

* The surface treatment of the equipment is anodizing, with bright color. It can be processed by sandblasting, brushing and other processes, and various colors can be customized .

* The product panel and metal touch panel are made of high-quality aluminum and CNC engraved . The device panel is only 2mm thick and 45mm wide. The ultra-thin panel looks more high-end.

* It has the function of rapid lifting in 10 seconds; it also adopts a low-noise design, with operating noise less than 42dB.

* The device has an RJ45 interface and uses a one-line network power supply. It can realize device power supply and data transmission functions through a network cable.

* The device has a RESET button. Press and hold it for 3 seconds to reset the device IP and clear the nameplate information on the screen.

* Innovative metal touch control, no physical buttons, the overall appearance is simple and elegant , and it uses capacitive sensing technology. When the user touches the touchpad on the top of the screen for 3 seconds, the screen automatically rises or falls.

* Can be controlled centrally or individually through electronic nameplate management software .

* After the nameplate rises, the screen automatically powers on, and after it falls, the screen automatically cuts off the power, saving energy and protecting the environment.

* Supports creating meetings through the software, and can reserve meeting times, meeting rooms, and import/add participants.

* It supports visual layout function, and can import the on-site layout diagram to uniformly issue nameplate information or issue nameplate information individually for each seat position; it also supports one-click screen clearing function.

* Nameplate settings function: Offers a wide range of background color options, allowing customers to select different background colors via hexadecimal color codes. Users can also choose to change the background image, with six pre-set background images available, as well as support for custom background images. It also supports switching font types, font sizes, and text colors.


Specifications:


Lifting time

10 S

Screen

Dual screens with the same display, no touch support

Screen display size

7 inches, 154.21mm (W) x 85.92mm (H)

Screen ratio

16:9

Screen resolution

1024×600

Display dimensions

175.4 × 105.2mm

Display thickness

12mm

Contrast

1000

Brightness

300cd/m²

Backlight mode

led

Viewing angle

80/80/80/80 (Typ.)(CR≥10)

Machine weight

1.2 Kg

Product dimensions

213×45×228.7mm

Panel dimensions

213×45×2mm

Chassis dimensions

204.5×37×226.7mm

Desktop opening dimensions

206×39mm (physical opening recommended)

Panel sink dimensions

214×46×2mm (length × width × thickness) (physical opening is recommended)

Environmental conditions

-20℃50℃, relative humidity ≤70%

Power supply mode

PoE (IEEE802.3af)

Power consumption

9W
