* Engineering plastic injection molding cabinet, good weather resistance, high strength, and light weight.
* The coaxial structure design of an efficient 12-inch mid-woofer and a 44-core compressed driver.
* High sensitivity, high power, long transmission distance.
* Steel surface mesh, built-in three layers of mesh cloth and acoustic cotton with breathable and waterproof functions, in accord with IP56 International standard.
* Equipped with a standard hanger with galvanized steel spraying treatment and matching stainless steel screws and safety ropes, which are convenient and safe to install.
* It is mainly used in school playgrounds, theme parks, cultural squares, stadiums, etc.
Frequency response |
55Hz ~ 20KHZ @ -10dB |
Rated power |
75W, 150W, 300W/100V, 300W/8Ω optional |
Peak power |
1200W |
Max SPL(rated/peak) |
123dB/129dB |
Sensitivity |
98dB±3dB@ (1W/1m) |
Coverage angle |
(H) 90° (V)90° |
Speaker unit |
12" woofer ×1, 1.7" compressed tweeter ×1 |
Dimension |
407×410×378mm |
Weight |
20Kg |
