* Engineering plastic injection molding cabinet, good weather resistance, high strength, and light weight.
* The coaxial structure design of an efficient 8-inch mid-woofer and a 34-core compressed driver.
* High sensitivity, high power, long transmission distance.
* Steel surface mesh, built-in three layers of mesh cloth and acoustic cotton with breathable and waterproof functions, in accord with IP56 international standard.
* A standard hanger made of spray paint galvanized steel sheet and the matching stainless steel screws and safety ropes make it convenient and safe for the installation.
* It is mainly used in school playgrounds, theme parks, cultural squares, stadiums, etc.
|
Model |
TS-108HT |
|
Frequency response |
75Hz ~ 20KHZ @ - 10 db |
|
Rated power |
37.5W, 75W, 150W/100V, 150W/8Ω optional |
|
Peak power |
600W |
|
Max SPL(rated/peak) |
117dB/124dB |
|
Sensitivity |
96db±3db @ (1w/1m) |
|
Coverage angle |
(H) 90° (V) 90° |
|
Speaker unit |
8" woofer ×1, 1.4" compressed tweeter ×1 |
|
Dimension |
300×302×280mm |
|
Weight |
11Kg |
Please leave a message if necessary, we will contact you as soon as possible!
