Feature：
* Digital transmission link, connected to the conference controller cascade port for power supply through network cable; uncompressed audio transmission technology, 48K sampling rate, 80Hz-16KHz bandwidth perfect sound quality.
* Capacitive touch keys are adopted to ensure no key tapping sound and a good environment of the venue.
* The unit supports microphone control and voice control function by PC software.
* The chairman unit has the priority to turn off the delegate unit.
* With standard TCP/IP protocol, support ICMP, HTTP, UDP, TCP, IGMP and other protocols.
* Support PING packet function.
* The unit has an independent web control page, which supports adjusting parameters such as microphone ID number and microphone sensitivity.
* The unit has voice control function, and the voice control sensitivity is adjustable.
* Support sign-in function. You can also disable and control the unit check-in, and other functions through the PC software.
* Support firmware upgrade function on the web page.
* Support the IP address sniffing function. And the ID number, IP address, MAC address and other parameters of the unknown unit can be found through the PC tool.
Specification:
|
Model |
TS-0315 |
TS-0315A |
|
Microphone type |
Electret capacitive |
|
|
Microphone directivity |
Cardioid |
|
|
Frequency response |
80Hz~16KHz |
|
|
Microphone input impedance |
1KΩ |
|
|
Sensitivity |
-37±1dB (0dB=1V/Pa,at 1KHz) |
|
|
Maximum SPL |
120dB(THD>3%) |
|
|
SNR |
>80dB(A) |
|
|
Crosstalk |
>70dB |
|
|
Dynamic range |
>80dB |
|
|
THD |
<0.1% |
|
|
MAX power consumption |
2W |
|
|
Power supply |
Conference controller |
|
|
Color |
Space gray |
|
|
Sign in |
Key |
|
|
Dimension (LxWxH) |
99*114.4*18.5mm (excluding the length of microphone rod) |
|
|
Microphone rod |
180mm space gray |
|
|
Installation method |
Desktop |
|
|
Weight |
0.62kg |
|
Please leave a message if necessary, we will contact you as soon as possible!
