TS-9110B Interactive Intelligent Touch Screen

The Details Related Solution Related Cases Related Video Download


Description:


It is a voice touch screen developed based on the Android system. It uses a 10.1-inch high-definition screen with a resolution of 1920×1200. The picture quality is exquisite, and the central controller supports switching matrix display screens and device switches through voice control; It is suitable for various medium and high grade meeting rooms, control centers and other occasions.


Feature:


* The device adopts a 10.1-inch high-definition screen with a resolution of 1920×1200, exquisite picture quality, and five-point touch with G+FF technology.

* Support privacy protection function. The touch screen has a physical privacy paddle, which can be slid to cover the camera to protect user privacy.

* Support scene calling. With the central controller, multiple scene modes such as conference mode, movie viewing mode, and unmanned mode can be preset. The touch screen only needs one-key operation to complete the linkage start or switch of all devices in the scene, avoiding cumbersome operation steps.

* Support signal preview. With the central controller, the user can view the conference camera screen through the control terminal and adjust the device according to the conference screen, and supports viewing multiple screens.

* Built-in 4 pickup microphones, the pickup distance can reach up to 7 meters; with the central control host, it supports functions such as switching matrix display screens and device switches through voice assistants.

* Built-in distance sensor, with sensing the position of the human body, the screen will light up when people come.

* With an indicator light, the display status of the indicator light can be switched according to the meeting status, and the usage of the meeting room can be checked without approaching.

* Support IP login, cloud control login, platform login and other login methods, enter the interface to control the controlled equipment.

* Support status feedback, the operator can check the switch status of all equipment on the panel.


Specification:


CPU

RK3566 Quad-Core Corte×-A55,2.0G

RAM

2GB

Memory

8GB

Operating system

Android 11.0

Display screen

IPS LCD screen

Resolution

1200×1920

View area

135.36×216.576mm

Contrast

800 min/1000typ

Brightness

370(min) / 450(typ)/530(Ma×)cd/

Aspect ratio

1610

Touch screen

10.1 inches G+FF

Light bar

Single color indicator light (BLUE)

Media player

Video format 4Kp60 H.264/H.265/VP9 profile0 2

1080P60 H.264, H.265

Audio format MP3, AAC, FLAC, WAV

Picture format JPG, JPEG, GIF, BMP, PNG

Speaker

8Ω 1W×1

Camera

Front 500W

Communication port

2, 10M/100M adaptive Ethernet

Back port

Support network port and 485 serial port output, suitable for embedded installation

Other port

1 external USB 3.0 interface, RS485 interface

WiFi/3G/4G/Bluetooth

Support WIFI2.4G/5G 802.11a/b/g/n/ac, BT-5.0

Power supply

100~240VAC,50/60Hz

Overall power consumption

≤7W

Standby power consumption

≤5W

Working temperature

0-50 ℃

Operating temperature

0-50℃

Operating humidity

Humidity≤85%RH

Storage temperature

-20-75℃

Storage humidity

Humidity≤95%RH

Colour

Silver gray

Package size (W x H x T)

375×215×80mm

Weight

0.62kg

Dimension (L×W×D) mm

242.6×167.68×9.8mm
