Description：

The light controller adopts two control modes: serial port and network. It integrates 8-channel 0-10V dimming and DMX512 dimming control. It supports remote control of the  light brightness through the tablet or PC. It is no longer limited to ordinary button switch, which is easy to operate, energy-saving and environmental-protection

Feature：

* Protocol compatible: it can not only used with programmable central controller, but also fully supports third-party equipment control.

* ID selection: The machine has ID identification, which is for convenient system cascade expansion.

* It has eight channels of 0-10V dimming power. The dimming power can be a constant voltage dimming power or a constant current dimming power. The maximum driving current of each channel is 40mA.

* With one DMX512 light control interface, it can adjust up to 512 controlled channels, namely brightness of 512 lights.

* With reset button, it can restore to factory default settings.

* Indicator light: indicates the running status of the machine and the switch status of the machine.

* Network control: remote control via Ethernet; support for static IP settings and dynamic IP via DHCP. Fully support for third-party device control.

* RS232 control: It can be controlled through the central control serial port or the third-party equipment.

Specification：
