Feature:
* Color wheel: 7 color gels + white light, two-way stepless rotation, magnet positioning, color index, half-color and other functions.
* Gobo wheel: 6 rotatable gobo wheels, 6 gobos; support pattern positioning, rotation, dithering, etc.
* Function: a dynamic effect wheel, two-way stepless rotation.
* Prism: triangular prism, quadrilateral prism, four row lens and so on.
* Atomization, 10%-100%.
* Light spot changing, and high-speed electric linear zooming.
* Dimming: 0-100% linear adjustment.
* DMX512 port program update, convenient and fast software upgrade through DMX data cable.
* Over-temperature protection function: built-in NTC temperature control function. When the LED is overheated, the output power will be intelligently reduced.
* LCD blue screen display, including the lamp usage time, software version number, etc.
Specification:
|
Model |
TL-LT203 |
|
Input voltage |
AC 110-240V 50/60Hz, 350W |
|
Light source |
A 300W White Light LED OSRAM chip |
|
Average lifespan |
50000H |
|
Color temperature |
7500K |
|
Beam angle |
5°- 50°linear focusing |
|
Control mode |
Comply with the international standard DMX512 signal control protocol, 3-core (5-core optional) DMX512 signal interface; master-slave synchronous control mode, support RDM protocol and program online update function |
|
Operation mode |
DMX mode, user program mode, built-in program mode |
|
Channel |
15 channels |
|
Fixture material |
High-resistant aluminum alloy + high temperature resistant/UV resistant engineering plastic + copper tube radiator + a waterproof fan to assist heat dissipation |
|
Protection class |
IP67 |
|
Working temperature |
-20℃～45 ℃ |
|
Fixture size (L×W×H) |
541×267×346mm |
|
Net weight |
20.5kg |
