Feature:
* Color: 1 color panel: 6 colors + cooling gobo + white light, half-color effect, variable-speed two-way rainbow effect, step/linear color conversion is optional.
* Function: 2 water pattern panels, independent rotation, forward and backward stepless rotation; realize the natural water flow effect with the color changing.
* Dimming: 0-100% linear adjustment.
* Strobe: electronic strobe, 0-25 times/sec (built-in pulse stroboscopic effect).
* Spot: the light spot changes with high-speed electric linear zooming.
* DMX512 port program update, convenient and fast software update via DMX data cable.
* Over-temperature protection function: built-in NTC temperature control function; when the LED is overheated, the output power will be intelligently reduced.
* LCD blue screen display. The lamp usage time, software version number and others are displayed.
Specification:
|
Model |
TL-LT106 |
|
Input voltage |
AC 110-240V 50/60Hz, 535W |
|
Light source |
450W white light LED |
|
Average lifespan |
50000H |
|
Color temperature |
7000K |
|
Beam angle |
25°～50° electric adjustment |
|
Control mode |
Comply with the international standard DMX512 signal control protocol, 3-core (5-core optional) DMX512 signal interface; master-slave synchronous control mode, support RDM protocol and program online update function |
|
Operation mode |
DMX mode, user program mode, built-in program mode |
|
Channel |
9 channels |
|
Fixture material |
High temperature resistant aluminum alloy + high temperature resistant/UV resistant engineering plastic + copper tube radiator + 1 waterproof fan to assist heat dissipation |
|
Protection level |
Protection IP67 |
|
Working temperature |
-20℃～45 ℃ |
|
Fixture size (L×W×H) |
346×267×541mm |
