Feature:
* Color: one 5+1 fixed color panel, two-way stepless rotation, magnet positioning, color index, half-color and other functions.
* Function: 2 water pattern panels, independent rotation, forward and backward stepless rotation.
* Electric focusing, the spot can show various water ripple effects with the focal length changing.
* Dimming: 0-100% linear adjustment.
* Strobe: electronic strobe, 0-25 times/sec (built-in pulse stroboscopic effect).
* DMX512 port program update, convenient and fast software update via DMX data cable.
* Over-temperature protection function: built-in NTC temperature control function; when the LED is overheated, the output power will be intelligently reduced.
* LCD blue screen display. The lamp usage time, software version number and others are displayed.
Specification:
|
Model |
TL-LT102 |
|
Input voltage |
AC 110-240V 50/60Hz, 240W |
|
Light source |
One 200W white light LED OSRAM chip |
|
Average lifespan |
50000H |
|
Color temperature |
7500K |
|
Beam angle |
25°/45°/70°(optional) |
|
Control mode |
Comply with the international standard DMX512 signal control protocol, 3-core (5-core optional) DMX512 signal interface; master-slave synchronous control mode, support RDM protocol and program online update function |
|
Operation mode |
DMX mode, user program mode, built-in program mode |
|
Channel |
7 channels |
|
Fixture material |
High-strength die-cast aluminum alloy + copper tube radiator + 1 waterproof fan to assist heat dissipation |
|
Protection level |
Protection IP67 |
|
Working temperature |
-20℃～45 ℃ |
|
Fixture size (L×W×H) |
230×180×367mm |
|
Package size (L×W×H) |
270×250×455mm |
|
Gross weight |
10.0kg |
|
Net weight |
7.5kg |
