TL-LH3201/ TL-LH3202/ TL-LH3203 LED Flood Light

The Details Related Solution Related Cases Related Video Download


Description:


Application:Building facades, squares, leisure sports fields, stages, billboards, rockery, building exterior lighting, landscape lighting, signs and indicative lighting, entertainment venues and stage lighting, bridges, etc.


Feature:


* Smooth appearance curve, stylish and beautiful appearance. Cavity structure and independent heat dissipation are adopted to fully guarantee the stability and long lifespan of the LED;

* High-conductivity aluminum radiator, ventilation and convection design, smaller fixture and the larger power. SUS304 stainless steel screw bracket is equipped with a dial, with gear locking function;

* Glue-free waterproof design;

* The fixture is made of high-strength die-cast aluminum, and the surface is treated with fluorocarbon spraying. The lampshade is made of high-strength tempered glass, which is resistant to impact and friction;

* Good electromagnetic compatibility and no electromagnetic interference to the surrounding environment.

*  Built-in constant current driving circuit, allowing it to maintain efficient illumination. It operates stably over a wide voltage range, improving surge protection capability and avoiding flickering of the lights caused by changes in the external power supply voltage. During the process of connecting the lights in series, it ensures consistent brightness between the first and last light fixtures.



Specification:


Model

TL-LH3201

TL-LH3202

TL-LH3203

Input voltage/power

DC24V/15W

DC24V/10W

DC24V/10W

Number of LED lamp bead/ light source

CREE/4PCS

CREE/4PCS

CREE/4PCS

Beam angle

15°(30°、45°、60°optional)

Color temperature

3000K (1900K, 2100K, 4000K, 5700K optional)

Light effect

≥80lm/W

Color rendering index

Ra≥80

Color tolerance

SDCM≤5

Light source life

50000H

Control method

ON/OFF

IK Class

IK08

IP Class

IP65

Shell material

Aluminum + Tempered glass

Shell color

Sand gray

Installation method

Bracket screws

Product size

85*85*142mm

85*85*92mm

85*85*142mm

Packaging size

670*280*220mm

670*280*175mm

670*280*220mm

Net weight/Gross weight

1kg/12.8kg(10PCS)

0.8kg/10kg(10PCS)

1kg/12.8kg(10PCS)
