Description:
This is specific design for the market demand, for intelligent HD seamless mixed interpolation matrix designed DVI seamless input board, support for 4-way DVI video signal output, support digital HD 1080P signal, highly integrated board, the quantity of the boards is optional according to the requirement, it is very convenient for application and maintenance.
Features:
1. Support 4 CH DVI-D female interface seamless output.
2. Fast and seamless switching, no flicker, no black screen.
3. Support power off memory protection, unique function of ESD electrostatic protection..
4. Compatible with HDMI1.3a standard, HDCP1.3 protocol, DVI1.0 protocol.
5. Support upscaling function, the highest resolution is 1080P;
6. Support hot plugging,easy to use.
Specification:
|
Model |
TS-9404DO |
|
Protocol |
Support HDMI1.3a protocol, HDCP1.3 protocol, DVI1.0 protocol.
|
|
Pixel bandwidth |
165MHz full digital |
|
Interface bandwidth |
6.75Gbp, full digital |
|
Maximum support resolution |
Normal-PC： 1600x1200@60_24bit |
|
HDPC: 1920x1200P@ 60_24bit |
|
|
HDTV：1920x1080P@60_36bit |
|
|
Clock Jitter |
<0.15 Tbit |
|
Rise time |
<0.3Tbit (20%--80%) |
|
Fall time |
<0.3Tbit (20%--80%) |
|
Maximum transmission delay |
5nS(±1nS) |
|
Signal type |
DVI-D full digital T.M.D.S. signal in DVI 1.0 specification |
|
Signal strength |
T.M.D.S +/- 0.4Vpp |
|
Interface |
4-channel DVI-I female interface |
|
Minimum/maximum level |
T.M.D.S 2.9V/3.3V |
|
Maximum DC offset error |
15mV |
|
Maximum power consumption |
15W |
|
Weight |
About 0.5Kg |
|
Maximum distance between input and output |
15 meters |
