Feature:
* It can increase the loading capacity of the conference system and connect more conference microphone units.
* A dedicated 6-pin cable is used to ensure long-distance and reliable transmission of conference information and perfect sound quality.
* The housing is made of metal materials, and the connection between the circuit and the housing is strengthened with the ground wire to ensure the ability to resist static electricity at 6000V.
* The 2U metal cabinet can be installed in a 19-inch standard cabinet for easy placement and equipment maintenance.
* Built-in international universal power supply.
* Support three-channel synchronous extension, support the extension of 128 units.
Specification:
|
Model |
TS-0300ME |
|
Main power |
90~132VAC/180~264VAC by switch |
|
Maximum power consumption |
350W |
|
Output Power |
≤110W/36V per channel |
|
Connection method |
Special cable (6 PIN) |
|
RJ45 network port |
Connect the controller and the lower-level extension controller |
|
Colour |
Black |
|
Weight |
About 3Kg |
|
Dimension (LxWxH) |
484x305x88mm |
|
Operating temperature |
-10℃~+60℃ |
|
Operating humidity |
20%～80% relative humidity, no condensation |
