1. Dimming: 0-100% electronic linear dimming, smooth dimming technology without jitter.
2. Strobe: 0-25 times/second electronic strobe, adjustable speed, built-in random strobe or pulse strobe.
3. Color mixing system: RGBW (red, green, blue, white) linear color mixing; 16.8 million colors (saturation adjustable from 0 to 100%), with built-in macro function.
4. Features: High luminous efficiency, uniform color mixing, cast aluminum casing for good heat dissipation, with stable performance.
5. Software update: Support DMX signal update, cloud server remote online update. The software update is fast and convenient.
6. Display interface: Digital tube display; equipped with 4 mechanical buttons.
7. Temperature protection: Built-in NTC temperature control function. When the LED overheats during operation, it intelligently reduces the output power of the LED.
|
Voltage input |
AC 110-240V, 50/60Hz |
|
Rated power |
200W |
|
Power factor |
PF≥0.90 |
|
Light source |
61×3W LED(R13+G16+B16+W16) |
|
Average lifespan of light source |
50000H |
|
Color temperature |
3200K-7200K |
|
Color tolerance |
Single-color SDCM≤5 |
|
Luminous flux |
8228 lm |
|
CRI |
Ra≥75 |
|
Beam angle |
12° |
|
Spot angle |
25° |
|
Control mode |
DMX512 protocol, RDM protocol, with built-in Master-slave mode, Auto run mode, Sound-active mode, Manual control mode |
|
Channel mode |
Compact mode 4CH, Standard mode 6CH, Extension mode 8CH |
|
Voice control sensitivity |
65dB-130dB |
|
Casing material |
Cast aluminum casing |
|
Power connector |
1 power input connector, 1 power output connector |
|
Signal connector |
1 DMX512 input connector, 1 DMX512 output connector |
|
Working environment temperature |
-10℃～45℃ |
|
Protection rating |
Fire protection V-1, protection IP30 |
|
Product dimensions (L×W×H) |
312×233×368mm |
|
Package dimensions (L×W×H) |
290×290×420mm (carton) |
|
Package gross weight |
5.8kg (1pcs) |
|
Product net weight |
4.8kg |
