1. Dimming: 0-100% electronic linear dimming with jitter-free smooth dimming technology.
2. Strobe: 0-25 times per second electronic strobe with adjustable speed, built-in random strobe or pulse strobe.
3. Color wheel: 7 colors + 1 white, with adjustable speed and arbitrary positioning function.
4. Fixed gobo wheel: 8 fixed gobos + 1 white, with adjustable speed and arbitrary positioning function.
5. Prism: 6+12 prism, forward and reverse rotation with adjustable speed and arbitrary positioning function.
6. Display interface: Digital tube display with 4 mechanical buttons.
7. Temperature protection: Built-in NTC temperature detection function, intelligently reduces the LED output power when the LED operates over temperature.
8. Pan/Tilt range: Pan 540° (16-bit precision scanning) with electronic error correction, Tilt 172° (16-bit precision scanning) with electronic error correction, precise scanning positioning, signal feedback, and absolute position memory.
|
Input voltage |
AC 110-240V，50/60Hz |
|
Rated power |
150W |
|
Power factor |
PF≥0.90 |
|
Light source |
120W white light LED |
|
Average LED lifespan |
50000H |
|
Color temperature |
9000K |
|
Beam angle |
2.8° |
|
Control method |
DMX512 protocol, with built-in Auto run mode, Master-slave mode, Sound-active mode, Manual control mode |
|
Channel mode |
Compact mode 10CH, Standard mode 14CH |
|
Casing material |
V0 flame retardant ABS |
|
Power connector |
1 power input connector |
|
Signal connector |
1 RJ45 network input connector, 1 RJ45 network output connector |
|
Operating temperature |
-10℃～45℃ |
|
IP rating |
IP20 |
|
Product dimensions (L×W×H) |
178×178×340mm |
|
Package dimensions (L×W×H) |
367×265×233mm (carton) |
|
Package gross weight |
4.75kg |
|
Product net weight |
4.1kg |
