Description:
It works with professional amplifier and audio processor, forming a set of high-end entertainment sound reinforcement system with perfect sound effect and outstanding vocal performance. It is suitable for various karaoke rooms, bars, night clubs, etc.
Feature:
* A woofer and a tweeter imported from Italy.
* 15mm plywood housing, iron mesh cover, and dust-proof mesh cotton inside.
* Multiple screw hoisting holes, a pole socket with a diameter of 35mm, various installation methods.
* Four color options of the upper and lower covers: gold, silver (standard), red, blue.
Specification:
|
Model |
TM-10H |
TM-12H |
TM-15H |
|
Impedance |
8Ω |
8Ω |
8Ω |
|
Frequency response |
55Hz-20KHz |
50Hz-20KHz |
45Hz-20KHz |
|
Rated power |
300W |
400W |
500W |
|
Peak power |
1200W |
1600W |
2000W |
|
Sensitivity |
98dB/W/M |
99dB/W/M |
100dB/W/M |
|
Max SPL(rated/peak) |
123dB/129dB |
125dB/131dB |
127dB/133dB |
|
Coverage angle |
(H)90°(V)70° |
(H)90°(V)70° |
(H)100°(V)80° |
|
Tweeter |
1.4" compressed tweeter ×1 |
1.4" compressed tweeter ×1 |
1.7" compressed tweeter ×1 |
|
Woofer |
10" woofer ×1 |
12" woofer ×1 |
15" woofer ×1 |
|
Size (H×W×D) |
520×300×370mm |
570×350×440mm |
660×440×440mm |
|
Weight |
20.8Kg |
24.5Kg |
31.8Kg |
