T-6203 Voice Alarm and Recorder Controller

The Details Related Solution Related Cases Related Video Download


Description:


1. Equipment that receives short circuit trigger signal and plays alarm voice.

2. It is suitable for the broadcast system requiring fire alarm linkage.


Features:


*Standard cabinet design (1U).

* 2 alarm modes: Siren or pre-recorded voice alarm.

*2 emergency alarm modes are optional: stop the alarm immediately when the alarm short-circuit trigger is cancelled; after the alarm short-circuit trigger is cancelled, the alarm sound will play circularly (you need to manually press the stop key to cancel the alarm).

*3 alarm audio storage modes: 1 microphone recording input circuit; 1 recording input circuit; in addition, there is built-in alarm audio.

* Built-in recorder which can record 2 ~3 minutes voice message.


Specifications:


Model

T-6203

Indicators

Power indicator/Alarm status indicator

Power Supply

~110V-230V  50/60Hz

Power Consumption

30W

Dimension

484 x 209 x 44mm

Weight

2.30Kg
