Features：

1.Optical system: Employs a high-brightness coated honeycomb optical system. 2.Dimming: 0-100% electronic linear dimming, smooth dimming technology without jitter.

3. Strobe: 0-25 times/second electronic strobe, speed adjustable, built-in random strobe or pulse strobe.

4. Color mixing system: RGBW (red, green, blue, white) linear color  mixing; 16.8  million colors  (0-100% saturation adjustable), built-in macro function.

5. Fill light effects: strobe, running light effect, with built-in program. 6.Focusing: Linear electric focusing.

7. Scanning range: 270° Y-axis electric control (16-bit precision scanning), electronic error correction, precise scanning positioning, signal feedback, and absolute position memory.

8. Display interface: It adopts an LCD screen, is equipped with 5 mechanical buttons, supports a bilingual Chinese and English operating system, and can be rotated 180° for display.

9. Temperature protection: Built-in NTC temperature control function, which intelligently reduces the output power of the LED when it overheats.

Specification：



Input voltage

AC 110-240V, 50/60Hz

Rated power

760W

Power factor

PF ≥ 0.95

Light source 1

10*60W RGBW four-in-one LED beads (main light)

Light source 2

82*0.25W 5050 RGB three-in-one LED beads (auxiliary light)

Average lifespan of light source

50,000 hours

Color temperature

7800K

Beam angle

4°-37°

Control methods

DMX512 protocol, RDM protocol, built-in master-slave mode, self-running mode, voice control mode,



and manual control mode.

Channel modes

Simplified mode 17CH, Standard mode 27CH, Extended mode 1 99CH, Extended mode 2 108CH, Extended mode



3 168CH, Extended mode 4 170CH

Shell material

High-strength, high-temperature resistant engineering plastic shell with metal powder coating technology

Power interfaces

1 power input interface, 1 power output interface

Signal interfaces

1 DMX512 input interface, 1 DMX512 output interface

Operating ambient temperature

-10℃ to 45℃

Protection rating

IP20

Product dimensions (L×W×H)

1002×115×285mm

Packaging dimensions (L×W×H)

1080×380×395mm (carton)

Gross weight of package

40.3kg (2 pieces)

Product net weight

18.5kg
