Features：
1. Dimming: 0-100% electronic linear dimming, smooth dimming technology without jitter.
2. Strobe: 0-25 times/second electronic strobe, speed adjustable, built-in random strobe or pulse strobe.
3. Color mixing system: Linear mixing of warm white and cool white to adjust color temperature. Built-in strobe and running light programs.
4. Features: High luminous efficacy, excellent heat dissipation from the all-cast aluminum casing, and stable performance. Comes with a 1.3-meter-long power cord and signal cable (one inlet and one outlet) to improve on-site lighting layout efficiency.
5. Display interface: digital tube display; equipped with 4 mechanical buttons.
6. Temperature protection: Built-in NTC temperature control function, which intelligently reduces the output power of the LED when it overheats.
Specification：
|
1. Input voltage |
AC 110-240V, 50/60Hz |
|
2. Rated power |
450W |
|
3. Power factor |
PF ≥ 0.98 |
|
4. Light source |
4*100W LED (CW+WW) COB |
|
5. Average lifespan of the light source |
50,000 hours |
|
6. Color temperature |
Adjustable from 3200K to 5600K |
|
7. Color tolerance |
SDCM≤3 |
|
8. Luminous flux |
8624 lm |
|
9. Color rendering index |
Ra≥85 |
|
10. Beam angle |
60° |
|
11. Control method |
DMX512 protocol, with built-in master-slave mode, self-running mode, and manual control mode. |
|
12. Channel Modes |
Simplified Mode 2CH, Standard Mode 4CH, Extended Mode 1 6CH, Extended Mode 2 8CH, Extended Mode 3 12H |
|
13. Casing material |
High-strength die-cast aluminum alloy + 4 waterproof fans to assist in heat dissipation |
|
14. Power Interfaces |
One power input interface and one power output interface |
|
15. Signal Interfaces |
1 DMX512 input interface, 1 DMX512 output interface |
|
16. Operating ambient temperature |
-20℃ to 45℃ |
|
17. Protection rating |
IP65 |
|
18. Product dimensions (L×W×H) |
394×393×245mm |
|
19. Packaging dimensions (L×W×H) |
470×450×300mm (carton) |
|
20. Gross weight of packaging |
14.7kg |
|
21. Product net weight |
13.0kg |
Please leave a message if necessary, we will contact you as soon as possible!
