Features:

1. Optional switching of sensitivity 1V/2V, XLR balanced input/XLR balanced LINK output; SPEAKON audio socket output;

2. Dual-channel high-power professional digital amplifier;

3. The panel has signal (green), clip (orange), protection indicator (red), and power indicator (blue);

4. With signal, power and temperature pressure limiting functions;

5. With DC, short circuit, overload and overheat protection;

6. Equipped with a temperature-controlled fan, which works immediately when turned on. As the temperature increases, the fan accelerates and reaches full speed at about 60 degrees;

7. The normal load is 8 ohms, 4 ohms, and the minimum is 2 ohms.

8. Using variable oscillation modulation technology, multiple feedback control technology and innovative output power control technology, it has over 95% ultra-high efficiency and excellent stability;

9. Three modes of MONO/STEREO/BRIDGE can be selected and switched;

10. Output power (1KHz/THD≤1%):

1) Continuous power: Stereo 8Ω×2: 2*1000W; Stereo 4Ω×2: 2*1700W; Stereo 2Ω×2: 2*2900W; Bridged 16Ω: 2000W; Bridged 8Ω: 3400W; Bridged 4Ω: 5800W;

2) Maximum power*: Stereo 8Ω×2: 2*1500W; Stereo 4Ω×2: 2*2600W; Stereo 2Ω×2: 2*4350W; Bridged 16Ω: 3000W; Bridged 8Ω: 5100W; Bridged 4Ω: 8670W;
