* Dimming: 0-100% electronic linear dimming, jitter-free smooth dimming technology.
* Strobe: 0-25 times/second electronic strobe, speed adjustable, built-in random strobe or pulse strobe.
* Focus: Manual focus.
* Graphic cutting disc: 4 independent manual cutting discs, cutting at any angle to adjust the spot shape.
* Display interface: LCD display; equipped with 4 mechanical buttons; supports inverted display.
|
Input voltage |
AC 110-240V, 50/60Hz |
|
Rated power |
300W |
|
Power factor |
PF≥0.98 |
|
Light source |
300W White LED COB |
|
Average lifespan of light source |
50000H |
|
Color temperature |
4200K |
|
Color tolerance |
SDCM≤3 |
|
Luminous flux |
5698lm |
|
Color rendering index |
Ra≥95 |
|
Beam angle |
19° |
|
Control method |
DMX512 protocol, RDM protocol, built-in master-slave mode, manual control mode |
|
Channel mode |
Standard mode 2CH |
|
Housing material |
die-cast aluminum |
|
Power interface |
1 power input interface, 1 power output interface |
|
Signal interface |
1 DMX512 input interface, 1 DMX512 output interface |
|
Working environment temperature |
-20℃～45℃ |
|
Protection level |
IP65 |
|
Product dimensions (L×W×H) |
680×340×237mm |
|
Packing dimensions (L×W×H) |
750×530×745mm (carton) |
|
Gross weight of packaging |
13.6kg(1pcs) |
|
Product net weight |
11.9kg |
