Features:

1. The panel has AFC touch buttons and function working indicator lights.

2. With automatic gain function, it can effectively keep the microphone volume within a certain dynamic range. 3.It has automatic mixing functions, including gain sharing automatic mixing and threshold automatic mixing.

4. It has microphone voice excitation function and can set tracking threshold. When the microphone speech reaches the threshold, the camera tracking function can be linked.

5. It has AFC feedback suppression function and adopts notch + frequency shift dual mode. It can automatically capture the howling point and set the notch filter. The notch filter supports 12 fixed points + 12 dynamic points, which can effectively eliminate the howling function.

6. With EQ adjustment function, the output has 31-band graphic equalizer adjustment.

7. It has 2 network ports for connecting to wireless AP and communicating with conference host; it can connect to digital conference host through network protocol to realize audio data transmission.

8. It has 1 XLR balanced output and 1 RCA unbalanced output.

9. It has 1 RS-485 communication interface, which supports docking with cameras to realize camera tracking.

10. It has 1 RS-232 communication interface (voice transcription), supports docking with voice transcription server, and realizes voice transcription function.

11. It has 1 RS-232 communication interface (camera tracking) to connect to the central control system host or camera tracking host to realize the speech camera tracking function.

12. It has one EXTENSION interface, which can be used to connect to the extension port of the digital conference host. 13.Equipped with a digital conference host and automatic mixing function, it supports up to 16 wired microphones and 8 wireless

microphones at the same time.

Specification:
