Features:

* Supports switching between Chinese and English interfaces without restarting.

* Supports optional functions: mirror hot backup, all-pass filter, dynamic equalizer and other functions

* Supports channel parameter copy function, the same channel can quickly copy data, and the channel name can be customized.

* Supports full-function control of iPad touch screen and real-time data synchronization; supports simultaneous control of 8 terminals.

* Supports 8 fader groups, 8 user-defined buttons, and 4 quick mute group buttons.

* Supports 100 sets of scene preset functions, can be exported and imported to USB memory for easy data backup; supports 32 PEQ mode storage.

* Supports IPAD tablet, Android tablet, WIN system computer software control, and supports open central control code.

* The output channels support L/R, 10BUS, and HeadPhone (L/R), and the 10BUS mixing bus can be selected between pre-fader and post-fader (PRE/POST).

* Built-in signal generator: sine wave, pink noise, white noise.

* Built-in USB recording and playback functions. It can identify Chinese and English song names in the USB electronic disk, and has functions such as fast forward, next song, and quick pause, which is very convenient for on-site operation; and supports the playback of APE, FLAC, MP3, and WAV lossless audio formats.

* Built-in 16 channels of independent feedback suppressors, built-in 16 channels of automatic mixing (gain sharing type), with 8 DCA.

* Each input channel has 4-band parametric equalization, noise gate, high and low pass, compression, and inversion.

* Each output channel has 8-band parametric equalization, high and low pass, compression, inversion, and 1800 millisecond delay.

* ARM firmware and DSP firmware can be upgraded through the network or USB.

* It has powerful DSP processing capabilities and uses a touch control screen equipped with a professional digital audio processing interface. Professional buttons and touch screen can quickly operate various functional modules, such as level meter, PEQ, Limiter, USB recording and playback, scene storage, and system settings. wait.

* Equipped with panel lock button to prevent misoperation.

* It has 2 built-in effectors, including classic reverb, large room reverb and other effect modules; FX sound effects can be returned to the mix using a dedicated return channel and do not occupy the mono and stereo input channels.

* It has 17 100mm motorized faders that can control all channels and main outputs: 1 LR main channel fader, 16 channel faders and 4 fader layers.

* It has a professional operation panel composed of a 10.1-inch 1280x800 true color resistive touch screen, digital encoder and dedicated buttons, which can make all settings quick and easy.

* Wiring method: balanced input, output XLR.

Specifications :
