The product is a magnetic camera array microphone module, which is used with an interactive intelligent flat panel to provide a full range of high-quality conference audio-visual solutions to meet the needs of different scenarios.
* Built-in 12MP HD camera and 8-array microphone, the pickup distance can reach 10m.
* The camera array microphone is a detachable module with a 12-pogo pin magnetic interface design. It does not require separate wiring and uses physical protection to prevent the possibility of leakage of meeting information.
* When used with an interactive intelligent flat panel, panoramic mode and speaker tracking camera mode can be achieved.
|
Camera type |
Magnetic camera, pluggable, plug and play |
|
Drive standards |
UVC/UAC national standard, support USB2.0 protocol |
|
Electronic PTZ |
support |
|
Zoom |
3 times |
|
Focal length |
3 meters |
|
Pixel |
12MP |
|
Camera resolution |
640×480 30fps |
|
Image encoding format |
YUY2, MJPG |
|
Maximum field of view |
105 ° ±5° |
|
Horizontal field of view |
90 ° ±5° |
|
Vertical field of view |
60° |
|
Distortion rate |
＜-1.0% |
|
Angle |
15° down |
|
Video algorithm |
Automatic exposure control AE |
|
Camera module dimensions (length x thickness x height) |
292mm × 41mm × 33mm |
|
Microphone |
8 microphone |
|
Microphone pickup distance |
10m |
|
Sensitivity |
-38dB |
|
Signal-to-Noise ratio |
≥65dB |
|
Audio encoding format |
PCM |
|
Sampling frequency |
16k |
|
Number of sampling bits |
16bit |
|
Audio algorithms |
Echo Cancellation |
