T-7782POEH IP Network Column Speaker

The Details Related Solution Related Cases Related Video Download



Description:


It is specially designed for POE outdoor smart light poles, which can encode network signals into digital audio, and transmit them to terminals in designated area for playback through the network.


Feature:


* Professional integrated structure design, good cabinet sealing performance, fast-conducting all-copper nickel-plated grounding post; in line with the use and safety specifications in harsh outdoor environments, and the certification standard of IP54 protection class.

* Built-in one network digital audio decoding module, support IP/TCP, UDP and other communication protocols, realize the network transmission of 16-bit CD-quality audio signals.

* Built-in 25W digital amplifier module, delicate sound quality and strong power.

* Support unified server authorization to operate management functions, unified configuration to manage user and password functions; support 100-level custom audio priority mute control function.

* Compliant with IEEE802.3at standard, used with IEEE802.3at standard switches.

* Digital product, easy to extend, no geographical restrictions, no need to add management equipment in the equipment room, no wiring construction for common network, easy installation.

* DC24V power supply can be customized to meet the power supply needs of outdoor solar batteries.


Specification:


Model

T-7782POEH

Network interface

Standard RJ45 input

Communication protocol

TCP/IP, UDP

Audio format

MP3

Sampling rate

8K48KHz

Transmission rate

100Mbps

Audio mode

16-bit CD quality

Power

25W(MAX)

THD

≤1%

Frequency response

130Hz16KHz  +1dB/-3dB

SNR

≥68dB

Protection class

IP54

Working temperature

-20℃60℃

Relative humidity

20%80%, no condensation

Power voltage

Standard POE power supply

Maximum power consumption

30W

Speaker unit

2" × 4

Dimension

83×88×294mm

Weight

1.45kg
