Description:

* 4-channel HDBaseT output card supports single-link and dual-link output modes, and supports accompanying audio output;

* In the screen configured with the HDBaseT output card, the fade-in and fade-out switching effects are not supported;

* Single link input:

* Interface 1, interface 2, interface 3 and interface 4 can all output;

* Each channel supports up to 1920×1080@60Hz video output;

* Support custom resolution (limit width 2560, limit height 2560);

* Dual link output:

* Interface 2 and interface 4 can be configured as dual-link output, interface 1 duplicates the output of interface 2, and interface 3 duplicates the output of interface 4;

* A single channel supports up to 4096×2160@30Hz/3840×1080@60Hz video output;

* Support custom resolution (limit width 4096, limit height 4096);

Specification:
