TS-311M1 Microphone

The Details Related Solution Related Cases Related Video Download


Description:


The product uses an analog audio transmission circuit; the panel uses silicone buttons to effectively eliminate key knocking sounds and ensure a good venue environment; the equipment supports multiple power supply methods through 48V phantom power supply and battery power; it is suitable for various speech scenarios.


Feature:


* The use of silicone buttons can effectively eliminate key knocking sounds and ensure a good venue environment.

* With the microphone gain adjustment interface, the gain can be adjusted according to actual needs on site.

* Support phantom power supply and battery power supply; the battery supports 60 hours of continuous speech.

* With the battery power toggle switch at the bottom, the microphone battery power can be manually switched on and off according to the actual usage status, solving the problem of battery loss when the device is idle.

* With indicator light prompt when the microphone is turned on, after the button is turned on, the microphone pole indicator light turns red.


Specification:


Microphone type

Cardioid electret

Microphone core directivity

Cardioid

Frequency response

80Hz~16KHz

Output impedance

75Ω, balanced

Sensitivity

-38±2dB (0dB=1V/Pa,at 1KHz)

Max SPL

120dB

SNR

>80dB(A)

Crosstalk

>70dB

Dynamic Range

>80dB

THD

<0.3%

Maximum power consumption

0.1W

Power supply

Main 48V phantom power supply (Powered by AA battery)

Color

Graphite gray

Installation method

Desktop

Switch

Electronic touch

Microphone pole length and color

409mm black

Dimensions (L×W×H)

133.8×104.6×37.2mm

Weight

0.803kg (excluding battery)
