Description:
* With wide receiving angle range, in active state, the antenna can receive signals of about 100-120 meters in a straight line distance.
* With wide antenna receiving frequency band, it can receive frequencies of 470-950MHZ.
* Support anti-corrosion, anti-ultraviolet, anti-shock and light weight, and can work stably for a long time in different environments.
* Easy and convenient to install.
Feature:
|
Frequency Range |
470～950MHz |
|
Maximum gain |
8.0dBi |
|
VSWR |
≤2.0 |
|
Polarization mode |
Linear polarization |
|
Input resistance |
50Ω |
|
Connector model |
BNC connector |
|
Operating temperature |
-30～+60℃ |
|
Amplifier OIP3 |
>25dBm |
|
Directivity |
180° |
|
Supply voltage |
DC 8～12V |
|
Power supply |
Powered by receiver or distributor |
|
Antenna size |
207×117×44.5mm |
|
Net weight |
0.440±0.005kg |
