TS-615H Professional Speaker

The Details Related Solution Related Cases Related Video Download


Description:


It works with professional amplifiers and audio processors, forming a set of high-end entertainment and conference professional sound system with perfect sound effects and outstanding vocal performance. It is suitable for theaters, KTV rooms, high-end conference rooms and multipurpose halls, etc. It can also work with the subwoofer to compose a high performance satellite box.


Feature:


* Use a mid-woofer unit and an annular polyethylene diaphragm compressed tweeter.

* 15mm plywood housing, light weight, wear-resistant spray paint treatment and dust-proof net cotton outside.

* The accurately designed frequency divider optimizes the vocal IF performance.

* Multiple screw hoisting holes, a pole socket with a diameter of 35mm, various installation methods.

Specification:


Model

TS-615H

Impedance

Frequency response

45Hz~20KHz

Rated power

650W

Peak power

2600W

Sensitivity

100dB/W/M

Maximum SPL(rated/peak)

128dB/134dB

Coverage angle

(H)90°  (V)70°

Tweeter

1.73" compressed tweeter × 1

Woofer

15" woofer × 1

Dimension

660×435×430mm (H×W×D)

Weight

27Kg
