KS-206A Professional column speaker

The Details Related Solution Related Cases Related Video Download


Description:


Built-in two-way professional sound column, 6.5-inch large-diameter woofer, wide dynamic range, 1-inch treble compression driver loaded with waveguide, concentrated directivity; carefully debugged crossover network, vocals stand out and have high degree of restoration.

Suitable for use in conference rooms, banquet halls, lecture halls, command centers, and multi-function halls.


Feature:

* Uses two 6.5-inch specially customized high-efficiency speaker units and one 1-inch tweeter unit;

* The cabinet is made of 15mm plywood, and the surface is sprayed with environmentally friendly water-based wear-resistant and flame- retardant paint;

* Design and install a tweeter unit loaded with waveguide, which has good directivity, concentrated sound field and beautiful sound quality;

* Flexible installation system, multi-angle adjustment of sound field coverage, suitable for use in various occasions;

* Professional speaker sockets and plugs with good electrical characteristics.


Specification:

Type

Built-in two-way professional column sound

Rated power

300W

Peak power

1200W

Nominal impedance

Frequency range (-10dB)

90HZ-20KHZ

Sensitivity(±3dB)

97dB (1M/1W )

Maximum SPL (rated/peak)

122dB/128dB

Subwoofer

6.5" bass × 2

Tweeter

1" compression tweeter × 1

Coverage angle (-6dB)

90°H80°V

Net weight

11.6kg

Dimensions (H×W×D)

530×206×244(mm)
