Feature：
* Working mode: manual ON/OFF,automatic switch
* Protection function: output leakage protection
* Programmable number: 16
* Time control function: 1 time controller, the timing control range is 1min-168h, with automatic calibration function
Specification：
|
Input voltage |
AC380V, level -3P+N+E |
|
Wiring method |
AC380V three-phase five-wire system input, AC220V output directly connected to the output terminal of the air switch |
|
Power output |
AC220V，level -L+N+E |
|
Output power |
18*4KW |
|
Output channel |
18 channel AC220V |
|
Shell color |
White |
|
Installation method |
Wall-mounted |
|
Protection level |
IP55 |
|
Product size |
630*828.5*210.5mm（W*H*D） |
|
Package size |
900*700*275mm（W*H*D） |
|
Net weight |
35KG |
|
Gross weight |
37.5KG |
Please leave a message if necessary, we will contact you as soon as possible!
