Feature :

* Optical System: Utilizes high-temperature-resistant, high-transmittance optical glass (six-layer coating) with a φ150mm aperture lens.

* Dimming: 0-100% electronic linear dimming, supporting four dimming curves (square, reverse, linear, and S-curve) to meet the needs of various applications.

* Strobe: 0-25 times/second electronic strobe, with adjustable speed, supporting random and pulsed strobes.

* Color Wheel: 7 colors + 1 white light, bidirectional, infinitely rotatable, with magnetic positioning, color indexing, and half-color functions.

* Rotating Gobo Wheel: 6 rotating gobos with pattern dithering, forward and reverse rotation, adjustable speed, and arbitrary positioning.

* Dynamic Effect Wheel: 1 gobo wheel with a flowing water effect, forward and reverse rotation, and adjustable speed.

* Focus: Linear motorized focus.

* Zoom: 1-10x linear motorized zoom.

* Prism: One triangular prism, rotatable forward and reverse, with adjustable speed and arbitrary positioning capability.

* Atomizer: One atomizer plate, achieving a 10%-100% soft light atomization effect.

* Scanning Range: 540° or 630° on the X-axis (16-bit precision scanning), 270° on the Y-axis (16-bit precision scanning). Electronic error correction and non-contact magnetic rotary encoder positioning ensure precise scanning and positioning, signal feedback, and absolute position memory.

* Software Update: Supports DMX signal updates and remote online updates via a cloud server, making software updates fast and convenient.

* Display Interface: A 2.8-inch LCD display in Chinese and English, equipped with five mechanical buttons and a new visual UI, provides an intuitive operating experience. It supports switching between Chinese and English, and supports 180° font inversion.

* 1Real-time Monitoring: By monitoring the fan speed in real time, the fan's rotation status and speed are intuitively displayed on the screen, helping users better understand the device's operating status and heat dissipation.

* Intelligent Cooling: Utilizing a high-efficiency, adjustable-speed fan and intelligent temperature control algorithm, the fan speed is dynamically adjusted based on the internal temperature of the luminaire, balancing noise and heat dissipation efficiency.

* Temperature Protection: Multiple built-in sensors intelligently reduce the light source's output power or temporarily shut it down when the temperature exceeds a safe threshold.

* Scene Editing: Equipped with 20 independently editable scenes, a variety of scene lighting effects can be recorded and programmed on a single device.

* Pop-up Alerts: A pop-up alert automatically pops up when a device malfunctions or other issues occur, alerting the user to the problem and allowing them to take immediate action.

Specification:
