TV-MU650X USB Camera

The Details Related Solution Related Cases Related Video Download

Description:


This three-in-one design integrates the 4K UHD camera, beam-forming microphone and full-range speaker. It is specially designed for small and medium-sized conference rooms, especially huddle rooms with 4-6 people. It helps companies to rediscover the potential of internal small and micro conference spaces, so as to hold meetings more efficiently and save more rental costs.


Feature:


* Adopt a 1/2.5-inch, 8.51 million-pixel high-quality UHD CMOS sensor, 4K (3840x2160)@30fps UHD clear images, and backward compatible with 1080P, 720P and other resolutions.

* 121° wide viewing angle (110° horizontal field of view), 5x zoom, optical lens customized for conference scenes, built-in motorized PTZ (with a motion range of pan/tilt ±15°), and easier to take videos for conference participants.

* The built-in beam-forming microphone has a pickup distance of 6 meters. The low-distortion lateral beam-forming algorithm can guide the microphone directly  to the speaker, providing clearer, fuller and more realistic sound.

* Built-in 3A audio algorithm (AEC/AGC/ANS), full-duplex process, it can meet the communication needs of different room structures; no matter sitting at the conference table or standing up, they can talk comfortably and clearly.

* Built-in intelligent analysis algorithm, it recognizes the speaker's position based on the voice, automatically frames the speaker, automatically tracks the speaker and switches the speaker screen to make the speaker always clearly displayed in the center of the screen.

* Support flexible installation options such as desktop, wall mounting, TV/display mounting, making it easier to install and deploy in crowded conference rooms.


Specification:


Model

TV-MU650X

Video resolution

4K@30fps, 1080P@ 30fps, 720P@60/30fps, etc.

Sensor

1/2.5 inches, CMOS, effective pixels: 8.51 million

Optical lens

121°(DFOV), 110°(HFOV), 5x zoom, pan/tilt ±15°

PTZ

Mechanical PTZ (MPT) + Electronic PTZ (EPTZ)

Digital noise reduction

2D&3D digital noise reduction

SNR

≥55dB

BLC

Support

Full-range speaker

96dB SPL at 0.5 m

Microphone array

Beam-forming microphone, 6M pickup distance

Extended MIC

Connection type

Support (optional)

USB 3.0, backward compatible with USB2.0

Color space/compression

USB audio

MJPEG/YUY2

32K sampling rate, support UAC1.0

USB video communication protocol

UVC 1.1

UVC PTZ control

Support

USB interface

1*USB3.0, Type C; 1*USB2.0, Type A

Wireless communication

Bluetooth data communication (Bluetooth 5.0)

Installation method

Desktop, wall mounting, TV mounting, etc.

Standard cable

USB cable

Security protection

Anti-theft lock jack

Power supply

DC 12V, 2A (MAX)

Working temperature

0~40

Storage temperature

-40~60

Dimension (L*W*H)

600mm*117mm*135mm

Net weight

2.5kg
