Model

TV-820W

Wi-Fi module

5GHz/2.4GHz

Wi-Fi bandwidth

867MHz

Start Time

<15s

Screen sharing response Time

≤3s

Preemptive response time

≤2s

Support system

Windows7/8/10 Mac OS

Operation method

Plug and play, one-click projection

Pairing method

Insert into the USB interface of the receiving end and automatically pair

Transmission resolution

1920 X 1080

Frame rate

30fps and below

Power supply interface

USB2.0、3.0

Video transmission interface

USB2.0、3.0

Touch back

10 point @Windows/Mac OS

Operating temperature

+5°C ~ +38°C (+41°F ~ +104°F)

Storage temperature

-20°C ~ +50°C (-4°F ~ +104°F)

Operating humidity

0~90% relative humidity, non-condensing

Storage humidity

0~85% relative humidity, non-condensing

Net weight

88±5g

Fixture size

180×72×18mm (L×W×H)

Package size

216×105×30mm (L×W×H)
