Description:
It is mainly applicable to windowsill lighting of landscape buildings, ancient buildings, hotels, bridges, subway stations, entertainment venues, as well as landscape decoration of outdoor steps.
Feature:
* Unique appearance design, full of high-end temperament.
* High-conductivity aluminum radiator for good heat dissipation.
* Suitable for the frame-shaped structure object, making a frame-shaped arch effect.
* The linear light gives the subject a strong sense of contour and spatial hierarchy, and a full-angle halo can be formed through the combination of optical lenses and perfect lighting design.
* No dazzling glare whether viewed from the outside or inside the window.
* Built-in constant current driving circuit, allowing it to maintain efficient illumination. It operates stably over a wide voltage range, improving surge protection capability and avoiding flickering of the lights caused by changes in the external power supply voltage. During the process of connecting the lights in series, it ensures consistent brightness between the first and last light fixtures.
Specification:
Model
TL-LH5204
TL-LH5206
TL-LH5207
TL-LH5208
Input voltage/power
DC24V/12W
Light source
CREE/2PCS
Beam angle
3*180°
Color temperature
3000K
RGBW(W=5700K)
RGB
3000K
Light effect
≥30lm/W
≥20lm/W
≥20lm/W
≥30lm/W
Color rendering index
Ra≥80
Ra≥50
Ra≥50
Ra≥80
Color tolerance
SDCM≤5
Light source life
50000H
Control mode
ON/OFF
DMX512
DMX512
DMX512
IK level
IK08
IP level
IP66
Shell material
Aluminum + Transparent PC
Appearance color
sand gray
Installation method
screw fixed
Product Size
160*57*80mm
Package Size
535*375*305mm
Net weight/Gross weight
0.63kg/33kg(48PCS)
