TS-6200A Conference Chairman Unit

The Details Related Solution Related Cases Related Video Download



Feature:


* Adopt a new CNC design.

* Designed with a ring-shaped indicator light; red light indicates it is speaking, and green light indicates it is applying to speak.

* Unique microphone cover design, completely eliminate the low frequency "pop" noise without using a windproof cotton cover.

* The chairman unit is unrestricted by microphone modes or the number of spokesmen.

* The chairman unit has the priority to fully control the meeting order; it can be placed at any position in the loop, and the hand in hand connection mode is convenient for installation and maintenance.

* Windable condenser microphone pole, professional large cardioid condenser microphone core, extremely high sensitivity and voice clarity.

* Adjustable high microphone sensitivity.

* Support system controller power supply, and 24V input voltage.

* Adopt 8-pin wire with "T" shaped connection.

* Equipped with two 3.5mm stereo outlets, for recording and connecting headphones.

* Built-in high-fidelity speaker, support volume adjustment, and squealing suppression; when the microphone is turned on, the built-in speaker will automatically turn off.

* Support conference discussion/automatic camera tracking.


Specification:


Model

TS-6200A

Microphone type

Cardioid directional electret microphone

Frequency response

80Hz~16KHz

Input impedance

1KΩ

Sensitivity

-34±2dB(0dB=1V/Pa,at 1kHz)

Maximum SPL

100dB(THD>3%)

SNR

>80dB

Crosstalk

>70dB

Dynamic range

>80dB

THD

<0.1%

Maximum power consumption

2W

Headphone load

8-32Ω

Headphone volume

40mW maximum

Headphone jack

3.5mm mono jack

Standard

IEC60914

Connector

1.8m aviation 8-pin connector

Hand-in-hand extension port

Support

Power supply

Controller power supply DC24V

Color

Black

Weight

0.86kg

Microphone pole

409mm

Dimension

144×128×62mm (L×W×H)

Installation method

Desktop
