TS-0370H-8 Digital Infrared Transmitter

The Details Related Solution Related Cases Related Video Download



null



Description:


The digital infrared transmitter is the core of the digital infrared voice distribution system. It compresses and encodes digital audio into full digital DQPSK modulation for transmission, and the system can transmit 8 channels at the same time. The infrared transmitter can be installed in a 19-inch standard cabinet, which is easy to store and operate.


Feature:


* In line with IEC 61603-7.

* With 8 audio outputs, it can be used for monitoring or connecting a deck for recording.

* With 2 signal output interfaces (BNC), it can be connected to the radiation panel.

* Adopt full digital DQPSK modulation technology, with high security.

* High-speed DSP processing, beautiful sound quality.

* Adopt higher transmission frequency (2-6MHz, IEC61603 BAND4 frequency band), not interfered by high frequency driving light source.

* With input level indication function, the LED lights on the front panel can display the input status of the corresponding channel.

* With 8 audio inputs, it is suitable for large international conference venues.

* Compatible with full digital conference system, full digital conference audio can be obtained through the aviation cable, and infrared simultaneous interpretation can be performed.

* The power input is AC 100V-240V, 50-60Hz; it has passed the high voltage (3500V) test before leaving the factory to ensure compliance with safety standards.

* The housing is made of metal materials; the connection between the circuit and the hosing and the ground wire is strengthened to ensure the ability to resist 8000V static electricity.


Specification:


Model

TS-0370H-8

Number of interpreter units

378

Number of channels

8CH

Frequency response

High sound quality: 50Hz~20kHz Low sound quality: 120Hz~10kHz

SNR

>75dB(A)

Dynamic range

>80dB

Channel crosstalk

>80dB

THD

<0.05%

Input voltage

~96V-264V 50/60Hz

Audio input

LINE IN 0-7: 350mV unbalanced

Audio output

LINE OUT 0-7: 1V unbalanced

Output load

>1KΩ

Static power

25W

Connection method

BNC (standard 75-5Ω coaxial cable)

Connector reliability

Reliable

Working temperature

-10~+60

Working humidity

20%80% relative humidity, no condensation

Color

Black

Installation method

19-inch standard cabinet

Weight

4.23kg

Dimension (L×W×H)

484×305×88mm
