KS-14F Professional Three-frequency Coaxial Monitor Speaker

The Details Related Solution Related Cases Related Video Download


Description:


It is used in performance activities, stadiums, theaters, multipurpose halls and various high-end occasions.


Feature:


* The three-way coaxial listening speaker uses a 14-inch coaxial woofer and a 100mm+65mm imported neodymium coaxial mid-high compression driver.

* The 14-inch three-way coaxial speaker design is used to concentrate the tweeter, mid-range and bass units at the same point for divergence.

* The cabinet is made of high-quality imported birch wood, adopts precise CNC machining, polyurea spray paint, high-end and wear-resistant.

* With hanging parts, it can realize the function of stage sound monitoring.

* Support directional control with a wider frequency band; the 800-16KHz horizontal and vertical directions are controlled by the point sound source horn.

* The polygonal cabinet structure supports adjustable monitoring angle.

* Three-frequency single drive design.

* Professional speaker sockets and plugs with good electrical characteristics.



Specification:


Model

KS-14F

Rated power

500W

Peak power

2000W

Nominal impedance

8Ω

Frequency range

60Hz-20KHz

Sensitivity

104dB(1M/1W)

Maximum SPL (rated/peak)

131dB/137dB

Woofer

14" woofer × 1

Tweeter

100mm+65mm coaxial mid-tweeter × 1

Coverage angle (-6dB)

75°(H) 40°(V)

Net weight

26kg

Dimension (H×W×D)

420×580×480mm
