T-7772 Panel

The Details Related Solution Related Cases Related Video Download


Description:


It is suitable for ordinary classrooms, multimedia classrooms, offices, conference rooms, prisons, hospital departments, subways and other places to increase external control equipment and expand the functionality of IP network terminals.



Features:


* Professional integrated IoT type 86 box design, the whole structure is very sturdy.

* Built-in 4-inch configuration serial port display with 480*480 resolution.

* Built-in high-performance 32-bit dual-core processor, fast processing speed, stable and so on.

* Built-in industrial-grade terminal block and IP network terminal real-time communication interface.

* Support to control the volume control function of wall-mounted IP network terminal.

* Support network task equalizer adjustment, local wall-mounted terminal 5-segment equalizer adjustment can be set according to on-site needs.

* Support MP3 audio files in VOD server or local USB.

* Password setting: after the lock screen, the login password is required to carry out the corresponding operation setting to prevent other people from operating the setting and other problems.

* Local terminal information: check the terminal's current terminal name, IP address information, call code and other terminal information.

* Supports external control device functions: touch volume adjustment for external sound source input; touch volume adjustment for network tasks;

* The external control equipment is connected by blue and white cable (24AWG), and the connection distance is ≤15 meters.



Specifications:


Model

T-7772

Display screen

4 inch digital true color screen, capacitive touch screen

Display resolution

480*480

Interface

Industry standard terminal blocks、RJ45-485 protocol network port

Power Supply

DC 24V

Operating Temperature

-20℃~+50

Environment Humidity

10%~90%(relative humidity, no condensation)

Weight

0.5kg
