TV-8207 OPS Computer Module(I7)

The Details Related Solution Related Cases Related Video Download


Specification:


Model

TV-8207

Operating system

Windows®10/Linux

Processor

I7 (8 cores)

RAM

DDR4-16G

Hard disk

SSD-512G

Front I/O

1*HDMI1.4 (Support 4096*2160@30Hz), 1*DP1.2 (Support 4096*2160@60Hz); 3*USB2.0, 3*USB3.0, 1*RJ45, 1*MIC IN, 1 *Line OUT, 2 *Wi- Fi /BT ANT, 1*Power button, 1*Reset button

Rear I/O

1*80pin, 1*HDMI2.0 (Support 4096*2160@60Hz), 2*USB2.0, 1*USB3.0, 1*AUDIO OUT, 1*2.5/5.5 DC interface

Extension port

1*M.2 2280 PCIE 4X SSD

1*M.2 2280

WiFi/BT

Support M.2 2230 WiFi+BT module

Input voltage

DC-IN 12-19V

Dimensions (L*W*H)

180mm*195mm*42mm

Working/storage temperature

-5~45℃/-20~70℃

Working/storage humidity

10%~90%RH, no condensation/5%~95%RH, no condensation
