TL-SL764 96*4kw Digital Silicon Box

The Details Related Solution Related Cases Related Video Download


Feature:


* SCR chip, the core component of the silicon box, adopts imported materials with stable and reliable performance;

* Good heat dissipation device and forced air cooling device are combined with intelligent environmental protection control system;

* Efficient anti-interference choke coil has strong anti-interference ability, small noise,  220us-450us current rising time;

* Start loop setting, and preheating value setting;

* The dimming curve can be set to linear or on/off state, the value of which is 50%. Under the on/off state, when the input brightness value is greater than or equal to 50%, the corresponding output loop is full, otherwise there is no output.


Specification:


Power supply

Three-phase five-wire system AC380V±10%, frequency 50Hz±5%.

Rated input current

400A Rhino plug input 96×4KW, suitable for any load

Circuit protection

A main switch, and a high-breaking air switch with double protection of overload and short circuit

Circuit indication

Three-phase independent voltage, current and monitoring, and three-phase A.B.C indicator light indication

Signal interface

Digital DMX-512 (1990)

Output mode

Terminal type, bakelite plug 40A

Cabinet size

International standard 32U
