1．Dimming: 0-100% electronic linear dimming with jitter-free smooth dimming technology.
2．Strobe: 0-25 times per second electronic strobe with adjustable speed, built-in random strobe or pulse strobe.
3．Color mixing system: RGBW (red, green, blue, white) linear color mixing; 16.8 million colors (0-100% saturation adjustable), with built-in macro function.
4．Focusing: Linear motorized focusing.
5．Pan/Tilt range: Pan 540° (16-bit precision scanning) with electronic error correction, Tilt 250° (16-bit precision scanning) with electronic error correction, precise scanning positioning, signal feedback, and absolute position memory.
6．Display interface: Features an LCD display with 5 mechanical buttons, supports bilingual Chinese and English operating system.
7．Temperature protection: Built-in NTC temperature detection function, intelligently reduces the LED output power when the LED operates over temperature.
|
Input voltage |
AC 110-240V, 50/60Hz |
|
Rated power |
400W |
|
Power factor |
PF≥0.90 |
|
Light source |
36*10W RGBW 4-in-1 LEDs |
|
Average LED lifespan |
50000H |
|
Color temperature |
6500K |
|
Luminous flux |
15265 lm |
|
CRI |
Ra≥70 |
|
Beam angle |
15°-30° |
|
Beam spot angle |
15°-60° |
|
Control mode |
DMX512 protocol, with built-in Master-slave mode, Auto run mode, Sound-active mode, Manual control mode |
|
Channel mode |
Compact mode 16CH, Standard mode 9CH |
|
Casing material |
High-temperature-resistant plastic + molded alloy + cooling method: air-cooled |
|
Power connector |
1 power input connector |
|
Signal connector |
1 DMX512 input connector, 1 DMX512 output connector |
|
Operating temperature |
-10℃～45℃ |
|
IP rating |
IP20 |
|
Product dimensions (L×W×H) |
329×220×450mm |
|
Package dimensions (L×W×H) |
425×295×390mm (carton) |
|
Package gross weight |
9.35kg |
|
Product net weight |
8.85kg |
