TS-W301A Delegate Unit

The Details Related Solution Related Cases Related Video Download


Feature:


* Adopt 48kHz sampling rate, better than the CD quality, clear and bright sound; internal DSP audio processing, and no low-frequency popping impact sound; the internal feedback suppression function can effectively prevent squealing.

* Support the function of speech timekeeping and speech countdown.

* Support voice control function to adjust the voice control sensitivity, intelligently open the microphone and set the closing time.

* With 5-band EQ adjustment function (PC software input password can be adjusted), different sound effects can be adjusted according to the speaker's voice characteristics until the perfect effect is achieved.

* With custom voting function, flexible and convenient.

* Adopt 128-bit AES encryption technology, support WPA/WPA2 wireless security technology, prevent eavesdropping and unauthorized access, and provide higher confidentiality of the conference system.

* With a 4.3-inch color screen, it can display information such as microphone on/off, ID settings, power, signal strength; support multi-touch capacitive buttons.

* Support clock display function, including date and time: year, month, day, hour, minute.

* It comes standard with 6 high-capacity lithium batteries with a battery capacity of 14400mA/h, supports 17 hours of speech.

* It has a USB charging interface and supports 18W fast charging.

* Support Chinese, English, Russian, French four language interface switching.

* With two 3.5mm headphones interfaces, support connecting an external microphone.


Specification:


Model

TS-W301A

Microphone type

Cardioid directional electret microphone

Frequency response

80Hz~16kHz

Sensitivity

-41±1.5dB (0dB=1V/Pa,at 1KHz)

Max SPL

100dB

SNR

>80dB(A)

Crosstalk

>70dB

Dynamic range

>80dB

THD

<0.1%

Maximum power consumption

3W

Power supply

Battery

Colour

Gray

Voting function

5-key voting, 3-key voting, custom voting

Sign-in function

Key sign in

Display screen

4.3-inch color screen

Dimension

196*134*63mm (L*W*H)

Installation method

Desktop

Wireless frequency range

5GHz

Battery capacity

14400mAh

Weight

About 0.7kg

Working hour in standby mode

24 hours

Working hour in speech mode

17 hours

Working hour in mixed mode

17 hours

Microphone pole

409mm
